Copilot Retrieval API (Beta): What You Can Do Today

TL;DR

The Copilot Retrieval API is currently in Beta and designed for user-scoped retrieval over Microsoft 365 content.
You can only call it with user-delegated tokens; app-only is not supported yet. Use the OAuth 2.0 On-Behalf-Of (OBO) flow.
Indexing details are opaque; you don’t control how/when documents are indexed beyond standard M365 ingestion and policies.
Focus on correct auth, tenant and user permissions, and responsible query patterns; accept that indexing behavior may change.

What is the Copilot Retrieval API (Beta)?

The Copilot Retrieval API provides a programmatic way to ask Copilot to retrieve relevant snippets from Microsoft 365–scoped content (like SharePoint/OneDrive/Teams files) on behalf of a user. Think of it as a managed, compliant retrieval endpoint that respects the user’s permissions and organization’s policies.

Because it’s in Beta, capabilities, payload shapes, and performance characteristics can change. Treat it as an early-access interface: great for pilots and prototypes, not yet for strict SLAs.

Current reality and limits

Here’s what’s true today:

Delegated only

You must use user-delegated access. There is no app-only (client credentials) support yet.
Concretely: your backend needs to exchange a user token using the On-Behalf-Of (OBO) flow to call the API.

Indexing is opaque

You don’t get knobs to control indexing cadence, scoring, or storage internals.
Content availability and freshness follow Microsoft 365’s ingestion and compliance pipelines; expect eventual consistency, not immediate reflection of every change.

Security and compliance first

Retrieval strictly respects the calling user’s permissions, Microsoft 365 DLP/labeling, and tenant policies.
“If the user can’t access it in M365, the API won’t retrieve it.”

Authentication: using OBO (On-Behalf-Of)

Since only user-delegated tokens work, a common setup looks like this:

Frontend acquires a user token (e.g., with MSAL in the browser) for your API audience.
Backend exchanges that token using OBO to obtain a downstream token for the Copilot Retrieval scope.
Backend calls the Copilot Retrieval API with that downstream token.

Key implications:

Your app registration must be configured for the OBO flow (expose an API, add the appropriate delegated permissions, and allow token exchange).
Tokens are per-user; cache them carefully and handle refresh/expiration.
Use the minimum scopes required; don’t request broad delegated permissions you don’t need.

Minimal Node.js (msal-node) sketch

import { ConfidentialClientApplication } from '@azure/msal-node';

const msal = new ConfidentialClientApplication({
  auth: {
    clientId: process.env.AZURE_AD_CLIENT_ID!,
    clientSecret: process.env.AZURE_AD_CLIENT_SECRET!,
    authority: `https://login.microsoftonline.com/${process.env.AZURE_AD_TENANT_ID}`,
  },
});

export async function exchangeOnBehalfOf(userAccessToken: string, scopes: string[]) {
  const result = await msal.acquireTokenOnBehalfOf({
    oboAssertion: userAccessToken,
    scopes, // e.g., ["{retrieval-api-scope}"], subject to beta docs
    skipCache: false,
  });
  if (!result || !result.accessToken) throw new Error('OBO failed');
  return result.accessToken;
}

Call the retrieval endpoint with the downstream token:

import fetch from 'node-fetch';

export async function getRelevantPassages(downstreamToken: string, query: string) {
  const res = await fetch('https://graph.microsoft.com/beta/copilot/retrieval/query', {
    method: 'POST',
    headers: {
      'Authorization': `Bearer ${downstreamToken}`,
      'Content-Type': 'application/json'
    },
    body: JSON.stringify({ query }) // shape may change in Beta
  });
  if (!res.ok) throw new Error(`Retrieval failed: ${res.status} ${await res.text()}`);
  return res.json();
}

Notes:

Endpoint and request/response shapes are illustrative and may change during Beta.
Always consult the latest docs for exact scopes, URL, and payload format.

Minimal C# (Microsoft.Identity.Web) sketch

using Microsoft.Identity.Web;
using System.Net.Http.Headers;
using System.Text;

public class RetrievalClient
{
    private readonly ITokenAcquisition _tokenAcquisition;
    private readonly HttpClient _http;

    public RetrievalClient(ITokenAcquisition tokenAcquisition, HttpClient http)
    {
        _tokenAcquisition = tokenAcquisition;
        _http = http;
    }

    public async Task<string> QueryAsync(string userScope, string query)
    {
        var token = await _tokenAcquisition.GetAccessTokenForUserAsync(new[] { userScope });
        _http.DefaultRequestHeaders.Authorization = new AuthenticationHeaderValue("Bearer", token);

        var json = $"{{\"query\":\"{query}\"}}";
        var payload = new StringContent(json, Encoding.UTF8, "application/json");
        var resp = await _http.PostAsync("https://graph.microsoft.com/beta/copilot/retrieval/query", payload);
        resp.EnsureSuccessStatusCode();
        return await resp.Content.ReadAsStringAsync();
    }
}

Again, treat this as a structural example, not a final SDK binding.

What you can (and can’t) influence

You can influence:

The user experience: prompt quality, query construction, and retrieval timeouts/retries.
Auth robustness: correct OBO implementation, token caching, and error handling.
Governance: ensure your app only requests the minimal delegated scopes and logs requests for auditing.

You can’t (today):

Force reindexing or tune ranking algorithms.
Use app-only tokens to perform broad, service-level retrieval.
Bypass user permissions; results always reflect the calling user’s access.

Practical guidance for pilots

Expect eventual consistency. If a file just changed, the retrieval result may lag.
Design for graceful degradation: handle empty/noisy results and timeouts.
Log correlation IDs and response metadata to help Support/IT investigate issues.
Build an admin “auth health” check that validates OBO configuration and scopes.
Communicate limits to stakeholders early: “Beta, delegated only, opaque indexing.”

Using filters effectively (Beta)

Filters help you narrow scope, reduce noise, and improve latency. In Beta, treat filters as best-effort hints that still pass through permission and policy trimming.

What to try in pilots:

Scope narrowing
- Limit to specific SharePoint sites, drives, folders, or Teams channels when available.
- Prefer “closest known container” over whole-tenant.
Content type
- File types: docx, pptx, xlsx, pdf, txt, md, etc.
- Exclude large binaries or media if not relevant.
Time windows
- Filter by modified/created after a certain date (e.g., “last 90 days”).
Ownership/people
- Prioritize documents authored by or shared with specific users or groups.
Business metadata (when supported)
- Project codes, labels, or repository hints relevant to your context.

Illustrative request shape (subject to change in Beta):

{
  "query": "account escalation runbook",
  "filters": {
    "locations": [
      "sharepoint:siteId:00000000-0000-0000-0000-000000000000",
      "teams:channelId:19:abc...@thread.tacv2"
    ],
    "fileTypes": ["docx", "pptx", "pdf"],
    "modifiedAfter": "2025-09-01T00:00:00Z",
    "owners": ["alexw@contoso.com"],
    "labels": ["Confidential", "Public"],
    "maxSnippets": 8
  }
}

TypeScript call sketch with filters:

export async function getPassagesWithFilters(token: string, query: string) {
  const body = {
    query,
    filters: {
      fileTypes: ["docx", "pptx"],
      modifiedAfter: new Date(Date.now() - 1000 * 60 * 60 * 24 * 90).toISOString()
    }
  };
  const res = await fetch('https://graph.microsoft.com/beta/copilot/retrieval/query', {
    method: 'POST',
    headers: { 'Authorization': `Bearer ${token}`, 'Content-Type': 'application/json' },
    body: JSON.stringify(body)
  });
  if (!res.ok) throw new Error(`Retrieval failed: ${res.status} ${await res.text()}`);
  return res.json();
}

Notes:

Exact filter names, accepted values, and combinations may change during Beta—validate against the latest docs.
Filters reduce candidate space, but the service still enforces permissions, labels, and policies before returning results.

Permissions, compliance, and sensitivity labels

Retrieval results are always permission-trimmed and policy-aware.

Permission trimming
- Only content the calling user can access will be retrieved. SharePoint/OneDrive/Teams permissions apply as usual.
- Expect empty results or 403/401 in cases of insufficient access or token issues.
Compliance and DLP
- Microsoft 365 compliance (DLP, retention, conditional access) can suppress, block, or alter what is returned.
- Your app must handle blocked/empty results gracefully and avoid retry storms.
Purview Sensitivity Labels
- Labeled and/or rights-managed (encrypted) content returns only if the calling user has rights; otherwise it’s excluded.
- Don’t assume label names are surfaced in responses; prefer server-side filtering when supported, or post-filter in your app carefully.
- Avoid caching labeled content across users. Cache per-user and respect token expiration.
Audit and traceability
- Calls are logged under your tenant’s normal auditing pipeline. Log correlation IDs you receive to help admins investigate.

Practical tips:

Start with narrow scopes (known sites/folders) and only widen when needed.
Prefer whitelisting file types over blacklisting.
When troubleshooting “missing” content, test access in the native M365 client first—if the user can’t open it there, retrieval won’t return it.

Developer checklist custom APP ✅

App registration created; backend is a confidential client (client secret/certificate).
OBO flow wired: frontend acquires a user token, backend exchanges it for retrieval scopes.
Minimal delegated scopes requested, consented, and verified in pre-prod.
Error handling in place for 401/403, throttling (429), and transient failures.
Logging and privacy: no PII in logs; secure storage for secrets.
